Siglent offers several series of spectrum analysers, of which you can find a brief overview below.
In the case of a VNA, both the amplitude and phase (S11 and S21) of the signal are determined.ĮEVblog also made a video about the SVA1015X with examples and explanations of the VNA function, which you can view here. The SIGLENT SNA5002A is the 9 kHz 4.5 GHz Vector Network Analyzer with support for 2 ports scattering-parameter, differential-parameter, and time-domain parameter measurements. These performances are displayed in S-parameters (scattering parameters, more information on these parameters can be found at Wikipedia). Package with measurment cables and adaptors for use with Siglent network analyzers and other instruments. Siglent SNA5002A 9 kHz 4.5 GHz Vector Network Analyzer. With the VNA you can determine the performance of radio frequency and microwave equipment by means of reflection and transmission coefficients. Update! The SVA1015X is now delivered with VNA license by default. There are also options available for this spectrum analyser to meet your requirements and preferences.
This analyser comes standard with support for a tracking generator. This spectrum analyser has a preamplifier, which means that the average noise experienced by the device is -156 dBm/Hz. This spectrum analyser has a large 10.1" LCD display and is equipped with advanced measurement functions. The Siglent SVA1015X spectrum and vector network analyser has an excellent price/quality ratio, as it has a frequency range of up to 1.5 GHz and has the functions of a vector network analyser. 0:00 / 35:23 SWR Measurements using a Bird 43, AIM-4170C, Siglent 3021X SA, & Agilent 8712ES VNA w8bya 985 subscribers Subscribe 13K views 5 years ago A demonstration of SWR measurement.
